Eas system with Advertising Light Box (Square) Location:Home > PRODUCT > Eas system with Advertising Light Box (Square)
服装店灯箱式广告防盗器
  • Brand: ZHONG AN
  • Type: Eas system with Advertising Light Box (Square)
  • Purpose: Applicable to all open-frame sales stores, such as clothing stores, shoe stores, jewelry stores, jewelry stores, supermarkets, pharmacies, cosmetics stores, etc.
  • Product properties: AM 58KHz/ RF 8.2MHz
  • Date of issue: 28 Apr 2020 10:09
  • Views: 1269 times
  • Tel: 0755-2665-3913
Detailed introduction
parameter
Product name AM EAS SYSTEM RF EAS SYSTEM
Product Mode
CG7-F
TR19-F
Patent No ZL 2015 2 0532575.8 ZL 2015 2 0532575.8
Working mode * Main machine can send and receive, single can work
* Slave machine must work with main, and one main machine can work with two slave
* Can receive and send, single can work
* One send and one(maybe two) receive work together
Advantages 1. Advertising revenue;
2. Wide detection distance;
3. Anti-interference ability;
4. Low voltage and low radiation-safety, energy saving and environmental protection;
5. Remote after-sales, convenient and fast.

1. Advertising revenue;
2. wide detection distance;
3. Anti-interference ability;
4. Remote after-sales is convenient and fast.

Material Acrylic panel + metal frame Acrylic panel + metal frame
Detection distance Soft label:2.2m; Small tag:2.5m
Middle tag:2.8m; Big tag:3.2m
4x4soft label:1.5米;
Small tag:2.0米; Big tag:2.4米
Work Frequency 58KHz 8.2MHz
Power supply Input:110-250VAC;Output:24VDC Input:110-250VAC;Output:24VDC
Power 10W 12W
Work temperature -20℃ ~ 55 ℃ -20℃ ~ 55 ℃
Ad iamge size 1270mm*350mm 1270mm*350mm
Product size 1525mm*400mm*90mm 1525mm*400mm*90mm
Package size 1570mm*150mm*450mm 1570mm*150mm*450mm
Net weight 14KG 14KG
Note
